BrainFPV RADIX F4 Flight Controller + gOSD (Custom Graphical OSD, Baro, Stackable, Betaflight)

BrainFPV RADIX F4 Flight Controller + gOSD (Custom Graphical OSD, Baro, Stackable, Betaflight)

0 reviewsWrite a review

US $4999

Product Code: BRAINF-RADIX
Availability: Out Of Stock

Qty

Description

Are you ready to experience one of the best flight controllers on the market for fpv mini quads, planes and wings? The BrainFPV Radix is here!

Introducing radix, the smartest, most innovative line of drone electronics BrainFPV has ever developed.

hello flexibility

radix is engineered to perfection with a visually stunning form factor and plug-and-play stacking. The radix flight controller stacks seamlessly on the radix power board or Hobbywing 4-in-1 ESC using soft cables for vibration isolation. Its simple, sophisticated design facilitates a faster build time and minimizes human error.

hello graphics

On top of the normal Betaflight OSD, radix on-screen-display gives you extra features you can’t get anywhere else. Proudly show off your pilot and team logo using our logo customizer with just a click of a button. Extra features also include a graphical barometer scale, artificial horizon, gyro spectograph, RC stick display, 3D OSD support and more!

Flight Controller	BrainFPV RADIX	BrainFPV RE1	Betaflight F4	Flyduino KISS FCv2
Processor	STM32 F4, 180MHz	STM32 F4, 180MHz	STM32 F4, 168MHz	STM32 F7, 216MHz
OSD	Full-graphic	Full-graphic	Character based	None (external)
Gyro	BMI160	BMI160	MPU6000	MPU6000
Baro	BMP280	BMP280 (optional add-on)	None	None
Logging Memory	MicroSD card slot	16MB built-in	16MB built-in	None (external)
Motor Outputs	6 with DSHOT	6 with DSHOT	4 with DSHOT	6 with DSHOT
Serial Ports	4	2.5 (UART3 is RX only)	4 (limitations due to fixed inverters)	5
BEC	5V, 2A with RADIX PB	5V, 1A / 10V, 1A with mPB V2	5V, 1.5A	5V, 500mA
Max Voltage	35V (8S) with RADIX PB	26V (6S) with mPB V2	?	6S (25.2V)
Max Current	100A (160A burst) with RADIX PB	80A (130A burst) with mPB V2	? 145A burst	- no PDB
Soft-mounting	Integrated grommets	None	None	None
Stacks on 4-in-1 ESC	Yes, plug-and-play	No	No	No
Firmware	Betaflight	Betaflight & dRonin	Betaflight	KISS
Price at Launch	$49.99 FC / $19.99 PB	$79 FC / $25 PB	$44.95	$66 (55.38 €)

Processor: STM32F446RET6, Coretx-M4, 32bit, 180MHz, 128kB RAM, 512kB Flash.
IMU: Bosch Sensortec BMI160 running at 3.2kHz, connected using SPI.
Baro: Bosch Sensortec BMP280 connected using SPI.
OSD: Full-graphic, PAL/NTSC auto detect, adjustable black and white levels. Full Betaflight OSD support with extra graphical features. Support for side-by-side 3D when used with a 3D FPV camera.
Memory: MicroSD card slot for logging.
Motor Outputs: 6 outputs with full DSHOT (150/300/600/1200) and OneShot support.
Receiver Support: PPM, S.Bus (inverter built-in), DSM, HoTT, SRXL, CSRF, FPort ready. 5V or 3.3V supply for receiver. Receiver is powered from USB for easy and safe setup.
Telemetry Support: FrSKY Smart Port, FrSKY Sensor Hub, HoTT Telemetry, SRXL, CSRF, FPort ready. Built-in inverter for FrSKY telemetry.

Serial Ports: 4 full serial ports (UARTs). UART3 and UART6 have inverters for S.Bus and SmartPort telemetry. Inverters are automatically enabled/disabled for maximum flexibility.
RGB LEDs: Dedicated RGB LED output.
Camera Control: Dedicated output for accessing the camera menu to change camera settings.
IR Emitter: Dedicated output for infrared based lap timing with multi-protocol support (I-Lap, Trackmate). Needs external IR LED and driver.
Buzzer Port: Dedicated port for 5V (100mA max) buzzers.
Analog Inputs: Voltage sensing up to 35V, current and RSSI inputs (3.3V max).
Power: 4.5V to 5.5V, 120mA.
Dimensions: 37mm x 37mm, 30.5mm hole spacing. 4.1mm holes for anti-vibration grommets.
Weight: 6g
